Bali Vertical Cellular Shades

Inside Mount

Inside Mount shades are installed inside the window casing or door, or wall to wall in a room. For inside mount recess requirements, see your designer or sales associate.

• Watch Video - Measuring for Inside, Side & Ceiling Mount

1. Measure the exact inside width of window casing from one inside edge to the other in three different places. Record the narrowest measurement.
2. Measure the exact height in three different places from top edge of opening to top of sill. Record the longest measurement.
3. Measure the window diagonally in two places, as shown. If the diagonal dimensions are not equal, we recommend an outside mount application for optimal function and aesthetics.
4. Do not take any deductions for clearance. The factory will take necessary deductions for a perfect fit.

Outside Mount

Outside mount shades are installed outside the window casing, covering an area larger than the window itself.

• Watch Video - Measuring for Outside Mount

1. Measure the exact width of window, including frame if there is one. Add 3" for each side (6" total overlap) to ensure light control and privacy.
2. Measure height of window from top edge of molding to bottom edge, or to top of sill if there is one. Add 3" to allow for adequate mounting area above the window.
3. If shade extends to floor (i.e. to cover patio door), measure height in three places, take the smallest measurement.
4. Do not take deductions. Allowances are made at the factory to ensure a perfect fit.
5. If you want the entire window uncovered when the shade is fully open, you may need to add more than 6" to the width. See designer or sales associate for additional guidance.

Video click here Inside mount  Outside Mount
